Precise1

Manual Hub/year/spline Information

Recommended Posts

Mile Marker Supreme Chrome 86.5-89 Pathfinder: PN-430, BS-6x3.260", 27 spline/1.094" OD
Mile Marker Supreme Chrome 90-01 Pathfinder: PN-435, BS-6x3.260", 28 spline/1.143" OD

Warn Premium:
Vehicle-----------------------------------------------Spline-----PN----Service kit PN
Pickup '84-86.5.................................................26.......29087...29061
Pickup, Pathfinder '86.5-89...............................27.......28739...29061
Pickup, 4 cylinder '90-93...................................27.......28739...29061
Pickup (incl. Frontier), 4 cyl '94-01....................28.......29091...29061
Pickup (incl. Frontier), Pathfinder, 6 cyl '90-01..28.......29091...29061
Xterra '00...........................................................28.......29091...29061

Added vehicles cross fitment.

Feel free to add in any other pertinent information including the 6 cylinder hardbody manual locking hubs. Thanks.

B

Edited by Precise1
Stupid forum software doesn't like spaces

Share this post


Link to post
Share on other sites

I belive CV's are interchangeable on all the 27 & 28 spline vehicles listed above....

So if you have a 27 spline and you found a cheap set of 28 spline locking hubs and your CV's just happen to need changed you could buy and install 28 spline CV's as your replacement instead of the 27's you originally had and vise versa.

Share this post


Link to post
Share on other sites

I believe you are correct.



Also, 4 wheel parts has both the Mile Marker Nissan hubs (430,435) on sale for $81.89 a set with free shipping if you order on line and pick up at a local store. That's the best price I can find, but it only lasts for a few days... :shrug:



B

Share this post


Link to post
Share on other sites

When I got my OEM Maual hubs @ the JY I went to nissan to see how much I would have spent for new ones. They could still get them and list price was $400 for a pair.

Share this post


Link to post
Share on other sites

The Mile Marker hubs are great guys. Have not put too much strain on them just yet, but at least now I have 4WD in reverse, and it doesn't come and go when it pleases...



And it cost quite a bit less than the Warn units.

Share this post


Link to post
Share on other sites

Thank you....



*Bookmarked*

Share this post


Link to post
Share on other sites

mile marker or warn? whitch are the better buy? my autos are giving out and i need something to replace them that wont crap out on the trail.

Share this post


Link to post
Share on other sites

mile marker or warn? whitch are the better buy? my autos are giving out and i need something to replace them that wont crap out on the trail.

Most people will argue that the Warn Premium are the best ones, but they are also the most expensive...



The factory Nissan manual hubs are the strongest of all, but are rare and sought after.



Did any of the older Frontiers or Pathfinders come stock with manual hubs?

Pathfinders, no, I don't believe so. Frontier, maybe?? The old hardbodys did which will work on pathfinders. Pre 93 and 4cyl are 27 spline (86.5-89 pathfinder) and 94+/6cyl are 28 spline (90-95 pathfinder) IIRC.



B

Share this post


Link to post
Share on other sites

The CVs are not all interchangeable. The older 27 spline CVs bolted to the front diff with 6 bolts in a 3x2 pattern. The newer 28 spline CVs are attached by 5 bolts in a 5x1 pattern. Sometime after 1995 Nissan went back to the 3x2 pattern and 28 splines.

Share this post


Link to post
Share on other sites

Frontiers and Xterras did come from the factory with manual locking hobs. Not sure if the X was a standard option or not?



I do have a set of 27 spline manuals sitting on my dresser that I can't use if anyone is interested.

Share this post


Link to post
Share on other sites

Can anyone tell me what size allen wrench or hex key you need to remove manual hubs? Im taking them off a 92 hardbody. And also what other tools do i need to remove these? Thanks for your time.

Share this post


Link to post
Share on other sites

Can anyone tell me what size allen wrench or hex key you need to remove manual hubs? Im taking them off a 92 hardbody. And also what other tools do i need to remove these? Thanks for your time.

Should be 6mm. Mine are. Also, use a quality allen wrench, you are going to have to use a cheater bar to get them off. I had to use a 18" tube to get my bolts off. I put a good bit of torque on those bolts before they gave way.

For the removal, an allen wrench is all you need. The hubs might be stuck on from friction. Bang them with you hand a little bit or give them a slight tab with a hammer.

Share this post


Link to post
Share on other sites

You can get square drive hex bits for use with ratchets too. Very useful... lets you use a torque wrench for installation for instance.

Share this post


Link to post
Share on other sites



I do have a set of 27 spline manuals sitting on my dresser that I can't use if anyone is interested.



pm'ed

Share this post


Link to post
Share on other sites

just wanted to point out another brand of manual hubs i have these from 4wd pros i have them on both my pathfinders and have not had a problem with them i think there like ruggedridge one but the only cost 70 bucks on ebay.






but on a side note anyone know where to get frontier xterra auto hubs for cheap

Edited by shoesandsocks

Share this post


Link to post
Share on other sites

I guess I've narrowed it down to 2 choices, within $16 of each other; AVN 461 for $132 or Mile Marker 435 Supreme for $116 (I found a set of 435s listed for a Sentra for $108, but no info as to spline count)

Anyone care to opine on the best choice?



Share this post


Link to post
Share on other sites

I guess I've narrowed it down to 2 choices, within $16 of each other; AVN 461 for $132 or Mile Marker 435 Supreme for $116 (I found a set of 435s listed for a Sentra for $108, but no info as to spline count)

Anyone care to opine on the best choice?



Share this post


Link to post
Share on other sites
